Optical Pyrometer - CellaTemp® PKL 68 (650 – 1600 °C)

The CellaTemp® PKL 68 detects the infrared radiation of the measuring object by means of a double photodiode in sandwich construction at the same time and place at two wavelengths. The temperature is determined from the ratio of the two radiation intensities.

request quote

The product

Special features:

  • Measuring range 650 to 1,600 °C
  • switching output universally configurable
  • high optical resolution due to precision lenses
  • IO-Link interface
  • all parameters can be set via pushbutton on the sensor
  • very simple mounting via M30 central thread
  • large and bright LED display
  • LED pilot light is permanently on as well as parallax-free and safe

Version

CellaTemp   PKL 68 AF 1

Measuring   range

650 –   1600 °C

Target   size

1,2   mm

Focus   distance

0,21   m

Shape of   the measuring field

round

Measuring   principle

two-colour

Sighting   option

LED   targeting light
Dispositivo de mira Puntero láser
